Description

Spesifikasi Produk

• Model : PLTS Hybrid 12 KVA 33 KWH Inverter 3 Phase

• Type : PLTS 12 KVA 33 KWH Inverter 3 Phase

• Kapasitas : 12 KVA – 33 KWH

• Sistem Operasi : Hybrid System

Komponen Utama

• Solar Panel : 22 unit – 550Wp Mono (Solar Panel 550-72HMI) → Total kapasitas 12.100 Wp

• Smart Inverter : 3 unit – 5042 1 Phase (5 KW)

• Baterai : 7 unit – 48V/100Ah

• Box Indoor : 1 unit (7x100Ah)

• AC Combiner Box (ATS) : 2 unit

• DC Combiner Box 2×10 KW : 1 unit

Aksesoris & Instalasi

• MC4 Connector 4 mm : 4 set

• Aluminium Rail 2,5 m : 45 batang

• Rail Joint Splice Kit : 24 set

• End Clamp 35 mm : 24 set

• Mid Clamp 35 mm : 60 set

• Tile Roof Hook : 60 set

Kabel & Koneksi

• Kabel PV 1×6 mm [PV – Inverter] : 300 meter

• Kabel NYAF 1×35 mm [Inverter – Battery +] : 30 meter

• Kabel NYAF 1×35 mm [Inverter – Battery -] : 30 meter

• Kabel NYM 3×6 mm [Inverter – Load] : 150 meter

• Kabel NYM 3×6 mm [GRID – Inverter AC Input] : 150 meter
